APPLICATION:

Purposed for outdoor fixed installations such as billboards or monument work, the ODX-P8S Outdoor offers high resolution video while retaining enough dependability and fortitude to withstand harsh conditions. With the backbone to handle inclement weather and a stunning image output that rivals its indoor-rated counterparts the ODX-P8S Outdoor is a flexible LED solution for nearly any fixed outdoor application.

TECHNICAL SPECIFICATIONS:

•  Pixel Pitch: 8mm
•  Drive Method: 1/4
•  LED Type: SMD3535
•  Brightness: ≥5,000cd/m2
•  Pixel Density: 15,625 pix/m2
•  Viewing Angle: 120°H and 120°v
•  Module Size: 256w x 128h mm (10.08 x 5.04 in)
•  Cabinet Size: 1024w x 768h mm (40.31 x 30.24 in)
•  Cabinet Weight: 43kg (94.79 lbs)
•  Cabinet Material: Sheet Metal
•  Average/Max Power Consumption: 300W/900W
•  Refresh Rate:≥1920HZ
•  Voltage : 110-240V
•  IP Rating: IP65
•  Operating Temperature : -20 - 50ºC
•  Life Span (hrs): ≥50,000
•  Compliance Standard: CE, RoHS, CCC
•  Typical Control System is NovaSTAR
