APPLICATION:

Purposed for outdoor fixed installations such as billboards or monument work, the ODX-P10D Outdoor offers high resolution video while retaining enough dependability and fortitude to withstand harsh conditions. With the backbone to handle inclement weather and a stunning image output that rivals its indoor-rated counterparts the ODX-P10D Outdoor is a flexible LED solution for nearly any outdoor application.

TECHNICAL SPECIFICATIONS:

•  Pixel Pitch: 10mm
•  Drive Method: 1/4
•  LED Type: DIP346
•  Brightness: ≥6,500cd/m2
•  Pixel Density: 10,000 pix/m2
•  Viewing Angle: 120°H and 60°v
•  Module Size: 160w x 160h mm (6.29 x 6.29 in)
•  Cabinet Size: 960w x 960h mm (37.79 x 37.79 in)
•  Cabinet Weight: 50kg (110.23 lbs)
•  Cabinet Material: Sheet Metal
•  Average/Max Power Consumption: 220W/650W
•  Refresh Rate:≥1920HZ
•  Voltage : 110-240V
•  IP Rating: IP65
•  Operating Temperature : -20 - 50ºC
•  Life Span (hrs): ≥50,000
•  Compliance Standard: CE, RoHS, CCC
•  Typical Control System is NovaSTAR
